CAS-24V-ZHAGA-4P-40-DA

CAS-24V-ZHAGA-4P-40-DA is one of OLFER Casambi outdoor control nodes.

This type is compatible with ZHAGA Book 18 sockets and enables easy autonomous control and dimming of DALI devices (drivers, electronic ballasts, etc.).

It is provided with an IP66, UV resistant, IK09 enclosure.
Electrical connection and mechanical fixing are done by twist and lock, without tools.

Main use is control of outdoor lighting applications.
By use of CASAMBI APP it is possible to group the luminaries by streets or areas, set dimming levels based on the time, schedule special events for specific dates, etc.
Remote control of the installation is also possible through the cloud by use of an internet connected device with Casambi App set up as gateway.

Communication range between control units is up to 70m outdoors (BLE4), and can be over 200m in BLE5 Long range type nets. Adding the control units to a net must be done individually with a mobile phone or tablet within range of each unit. For further installation setup and programming it is only necessary to be within the range of one of the control units.

Diverse operating modes are possible (on/off, dimming 0-100%, circadian control, tunable white, RGB. RGBW, etc.).

Different DALI communication profiles can be configured to match the luminaire requirements (see profile list in product datasheet).

Control unit temperature can be monitored in the App. Also internal data of DALI D4i drivers (power, etc).

It is compatible with other CASAMBI inside and CASAMBI ready products such as luminaries, motion sensors, relays, actuators, push buttons, etc.

CAS-24V-ZHAGA-4P-40-DA is IoT ready. It can receive information provided by a DALI D4i driver or ballast (power consumption, working hours, accumulated energy consumption, temperature, etc.) which can be sent to Casambi cloud by a device with internet connection and Casambi App set up as gateway. Access to this big data is possible through API and JSON protocol to exploit this information.

OLFER Casambi outdoor control nodes range:

• Nominal line voltage: 24Vdc SELV
• Input voltage range: 18-30Vdc SELV
• Power consumption standby: 0,6W @24Vdc
• Power consumption pulsed: 1,8W @24Vdc
• Output control interface: DALI/DALI-2
• Integrated DALI voltage source: 16Vdc (non isolated from input)
• DALI output current: 45mA max.
• Dimming range: 0-100%
• RF communication interface: Bluetooth 4.0 or 5.0 Low energy (BLE)
• RF communication protocol: Casambi
• Protections: Over temperature
• Temperature monitoring;: Internal temperature is displayed in Casambi App
• Operating temperature range: -40º to +70ºC
• Dimensions: Diameter 48mm. Height 44mm
• IP: 66
• Connector: ZHAGA Book 18
