4-way button interface

Buttons must be isolated according to the supply voltage (mains potential). Integrated antenna (drawing: gray area, do not cover with metal housing). Suitable for mounting in a flush-mounted box.

  • supply input: 220..240Vac; 50..60 Hz
  • radio signal: 2.4..2.483 GHz; 4dBm
  • power consumption: 2mA max
  • Ambient temperature (ta): 0..+55°C
  • Number of button inputs: 4
  • Cable length of the button inputs: max. 200 cm
  • short circuit protection
  • Dimensions: 45x29x17mm
