Estrella Pro Square Aperture

  • Exceptional glare control cellular system with single square glare control cells
  • TP(a) rated square aperture diffuser
  • Stand alone and continuous modules allow a creative design of continuous light lines
  • Multiple luminaires on a single power entry point
  • Tool free mechanical and electrical connections
  • Matte Black, white or grey body as standard, custom made RAL colours
  • Available in four linear sizes from 532mm to 2128mm, corner, T and + shapes
  • Low, standard or high output, efficacy up t0 125 Lm/W
  • Surface mounted or suspended, with optional direct/indirect light output
  • Excellent colour rendering index, CRI >90 Ra
  • Available in 3000K | 4000K | 5000K
  • Integrated tiltable spotlight available (Pulsar Lite)
  • Other optical options: Opal | Round Aperture | Wallwash | Louvre (Mirror, White, Dark)
  • Also available in Recessed with the same optical options

Read more

Light Source Information
· Direct light output
· Option for direct/ indirect (70%/30%) light output
· LED outputs available from ~1700 to ~6500 lm per meter
· Low, standard or high output available, efficacy of up to 125 Lumens per Watt
· Internal drivers supplied
· 90 colour rendering index
· Flicker-free for maximum eye comfort
· Colour Temperature 3000K | 4000K | 5000K
· L70 B50 = 100,000 hours | L90 B50 = 42,000 hours
· Single bin Samsung LEDs with a ≤3 step Macadam ellipse tolerance

Design
· Extruded aluminium profile
· IP40 Rated
· IK08 Rated
· Suspended or surface-mounted
· Available in 4 linear sizes 532mm, 1064mm, 15960mm and 2128mm
· Cross, corner and tee connections
· Available in White (RAL9016), Black (RAL9005) or Grey (RAL7046) as standard, custom RAL available on request
· Blank modules available

Optics
· TP(a) rated square aperture diffuser
· 90 degree beam angle
· Designed to achieve UGR<14

Installation
· Surface mounted or suspended (direct/indirect version can only be suspended)
· Can easily be connected into a continuous system
· Quick and simple power and control connection

Dimming
· Non-dimmable as standard
· DALI dimming available

Controls
· CASAMBI
· CP Sensor
· DMX
· Signify Easy Air
· Customised solution

Emergency
· 3hr integrated emergency available
· DALI addressable emergency

Anti-Microbial Protection
· Steritouch powder coating available

Miscellaneous
· 5 year warranty

To specify state:
Modular linear LED system with exceptional glare control and architectural aesthetic, for continuous or stand-alone configuration, that can be suspended or surface mounted. Available in a range of colour temperatures and lumen packages, tailored to your specification. Create continuous lines or angles of light – as RICOMAN Estrella Pro Square Aperture.
